bit spacing

5.0mm/5.08mm

number of digits

2-24P

Technical data

IEC

UL

Rated voltage

V

250

300

Rated current

A

12

10

Rated impulse voltage

KV

4

pollution level

3

Insulation Materials

PA66

Flammability rating

V0

Applicable ambient temperature

– 40℃~+105℃

can choose colour

5.0 pitch (grey); 5.08 pitch (orange)

Contact material

tinned copper

Solder pin size

1.0*1.0mm
